Applications : Power amplifier speakers protection
<<<<<< MORE kits ..... view other available kits >>>>>>
Protects your valuable speakers from damages by abnormal
dc voltages at the outputs of the power amplifier.
The circuit continuously checks
the dc voltages at the outputs of right & left channel.
If the dc voltage exceeds
around (+/-) 0.65V, this protector instantly disconnect the speakers from the amplifier
outputs
thereby preventing the speakers from damage
Applications : Power amplifier speakers protection
